Built-in Bluetooth® and wireless LAN
The camera offers built-in Bluetooth® version 3.0/4.2(Bluetooth Low Energy) and IEEE 802.11a/b/g/n/ac 2.4/5GHz wireless LAN, features that can be used for high-speed wireless connections not only to computers but also to smartphones* and other devices. The camera even supports WPS (Wi-Fi Protected Setup™) for easy wireless setup. In addition, the camera link to and exchange data with GPS receivers and other devices that support Bluetooth® version 3.0/4.0.
*Requires the latest smartphone application "Image Sync"
■Bluetooth® Transceiver
Feature | Specification |
---|---|
Data transfer | Bluetooth® standard version 3.0/4.2 (Bluetooth Low Energy) |
Output | Bluetooth® standard Power Class 2 |
Range*1 | Approximately 10m/33ft (line of sight) |
Supported Bluetooth® profiles*2 | BIP, OPP, SPP |
Operating band | 2.4GHz(CH0 ~ CH39) |
*1 Varies with such factors as signal strength, software, operating systems, and the presence or absence of obstacles.
*2 Specifications set out in the Bluetooth® standard to allow communication between Bluetooth® devices for specific purposes.
■Wireless LAN Transceiver
Feature | |
---|---|
Standards | IEEE 802.11a/b/g/n/ac |
Communication protocols | IEEE802.11g/n:OFDM IEEE 802.11b: DSSS, DQPSK, DBPSK |
Range* | Approximately 30m (98ft), varies with location and with operating environment and conditions |
Security | WEP (64/128-bit), WPA/WPA2 mixed PSK, WPA/WPA2 mixed EAP format enterprise EAP-TLS, PEAP (MS-CHAPv2) |
Operating band | 2.4GHz (1ch~11ch) / 5GHz (36ch~48ch) restricted to 2.4 GHz in infrastructure mode |
*Varies with such factors as signal strength, software, operating systems, and the presence or absence of obstacles.
