Digital Compact Camera: Optio M40

Optio M40 Specifications
Lens | PENTAX zoom lens, Optical 3X zoom 6 elements in 5 groups (4 aspherical elements) Focal Length: 6.3mm-18.9mm (equivalent to 36-108 mm in 35mm format) F Value: F3.1-F5.9 Capturing Area: approx. 47.0 mm× 35.2 mm to the fullest of LCD (at Super macro mode) Digital Zoom: approx. 4X |
---|---|
Shake Reduction | Still: Hi-sensitivity anti-shake mode (Digital SR) Movie: movie anti-shake (movie SR) |
Focus | Type: TTL contrast detection auto focus system 9-point AF, Spot AF, Auto tracking AF Still: Normal: 0.4m to infinity (whole zoom area. Tele only: 0.6m to infinity), 1.31ft to infinity (whole zoom area. Tele only: 1.97ft to infinity) Macro: 0.1m to 1.0m (at wide setting), 0.33ft to 3.3ft (at wide setting) Super macro: 0.05m to 0.4m, 0.16ft to 1.31ft Infinity-landscape mode: Infinity (whole zoom area) Manual Focus: 0.1m to infinity (at wide setting), 0.6m to infinity (other than wide), 0.33ft to infinity (at wide setting), 1.97ft to infinity (other than wide) * AF is fixed to Face priority AF at the Portorait and Natural skin tone mode. |
Sensor | 1/2.35 inch interline transfer CCD with a primary color filter, 8.50 megapixels (total pixels) |
Effective pixels | 8.0 megapixels |
Recorded pixels | Still: 8M(3264x2448), 5M(2592x1944), 4M(2304×1728), 3M(2048×1536), 2M(1600×1200),
1024(1024x768), 640(640×480) pixels Movie: 640(640×480), 320(320x240) pixels |
File Formats | Still: JPEG(Exif 2.2),DCF,DPOF,PRINT Image matching III Movie: AVI (motion JPEG), approx. 30fps / 15fps with sound Sound: WAV(PCM), monaural |
Quality Levels | Still: ![]() ![]() ![]() ![]() ![]() ![]() Movie: ![]() ![]() ![]() ![]() ![]() ![]() |
Sensitivity | Auto,Fixed (ISO 50/100/200/400/800/1600/3200) * The sensitivity is auto selected up to 3200 at the Digital SR mode. |
White Balance | Auto, Daylight, Shade, Tungsten light, Fluorescent light, manual setting |
LCD | 2.5 inch, TFTcolor LCD approx. 150,000 pixels Brightness level: 2 steps (Economy mode and Normal mode) |
Exposure Control | Metering System: TTL metering: Only multi-segment metering Exposure mode: "Picture mode, Program * AE is fixed to Face priority AE at the Portorait and Natural skin tone mode." Exposure Compensation: ±2EV(1/3EV steps) |
Capture modes | AUTO Picture, Program, Night Scene, movie, Voice Recording, Landscape, Flower,
Natural Skin Tone, Portrait, Surf&Snow, Sport, Digital SR, Kids, Pet, Food,
Frame Composition *Date Imprint Available |
Playback modes | Slideshow, Resize, Trimming, Image&Sound Copy, Image Rotation, Digital
Filter, Brightness Filter, Frame Composite, Red-eye Compensation, Voice memo,
Protect, DPOF, Start-up Image Setting Function: One Shot, Index (9 thumb nails), Enlargement (up to 8X, scroll available), movie Playback, Sound Playback, Histogram, Bright and Dark portion, Folder display, Select&Delete, Calendar Digital Filter: B&W, Sepia, Color Filter (6 colors), Color extract (B&W with Red, B&W with Green, B&W with Blue), Soft |
Movie | Shooting Time: Until the memory card becomes full (up to 2GB) Editing Function: - |
Shutter Speed | approx. 1/2000 sec.- approx. 4sec. |
Flash | Modes: Flash-on and Flash-off modes. "Red-eye" compensation function
employs a pre-discharge. Soft flash Effective Range: Wide: approx. 0.2m - approx. 8.0m (ISO Auto), approx. 0.2m - approx. 15.5m ( at Digital SR mode ) Tele: approx. 0.6m - approx. 4.0m (ISO Auto), approx. 0.6m - approx. 8.1m ( at Digital SR mode ) |
Drive modes | One shot, Self-timer (10 sec, 2 sec), Continuous, |
Storage media | Build-in memory (approx. 21.9 mB), SD memory Card, SDHC memory Card |
Clock Function | World Time: 75 cities (28 time zones) |
Power | Rechargeable D-LI63 lithium-ion battery, Optional AC adapter kit is also
available Battery life: Still: Approx. 220 (Rechargeable Lithium-ion battery) Movie: Approx. 80 (Rechargeable Lithium-ion battery) |
Interfaces | USB (2.0 Hi-Speed)/AV, DC Input terminal |
Video Output | NTSC/PAL |
PictBridge | Modes: Single image, All images, DPOF, Paper Size, Paper Type, Paper Quality, Border |
Dimensions | 97.5(W)×57.5(H)×18(D)mm (excluding protrusions) |
Weight | Body: 115 g (without battery and SD memory card) With battery & SD card: 135 g (loaded and ready) |
Languages | English, French, Germany, Spanish, Portuguese, Italian, Dutch, Danish, Swedish, Finnish, Polish, Czech, Hungarian, Turkish, Russian, Thai, Korean, Traditional Chinese, Simplified Chinese, Japanese |
Accessories | Rechargeable D-LI63 lithium-ion battery, Charger, AC cable, USB cable, AV cable, Software (CD-ROM), Strap |
Storage capacity
Recorded Pixels | Quality Levels | Built-in memory |
64MB | 128MB | 256MB | 512MB | 1GB | 2GB | 4GB |
---|---|---|---|---|---|---|---|---|---|
[8M] 3264 × 2448 |
![]() ![]() ![]() |
5 | 15 | 32 | 62 | 123 | 247 | 503 | 989 |
![]() ![]() |
11 | 30 | 62 | 121 | 239 | 479 | 975 | 1915 | |
![]() |
17 | 47 | 95 | 186 | 368 | 737 | 1499 | 2943 | |
[5M] 2592 × 1944 |
![]() ![]() ![]() |
8 | 24 | 49 | 97 | 192 | 385 | 778 | 1527 |
![]() ![]() |
17 | 47 | 95 | 186 | 368 | 737 | 1499 | 2943 | |
![]() |
24 | 67 | 137 | 267 | 530 | 1060 | 2119 | 4162 | |
[4M] 2304 × 1728 |
![]() ![]() ![]() |
11 | 30 | 62 | 121 | 239 | 479 | 975 | 1915 |
![]() ![]() |
22 | 61 | 124 | 242 | 479 | 959 | 1921 | 3771 | |
![]() |
31 | 88 | 178 | 346 | 686 | 1374 | 2794 | 5486 | |
[3M] 2048 × 1536 |
![]() ![]() ![]() |
13 | 38 | 77 | 151 | 299 | 598 | 1205 | 2366 |
![]() ![]() |
27 | 75 | 153 | 299 | 592 | 1185 | 2364 | 4642 | |
![]() |
40 | 110 | 223 | 435 | 863 | 1727 | 3415 | 6705 | |
[2M] 1600 × 1200 |
![]() ![]() ![]() |
22 | 61 | 124 | 242 | 479 | 959 | 1921 | 3771 |
![]() ![]() |
36 | 101 | 206 | 401 | 795 | 1591 | 3235 | 6352 | |
![]() |
54 | 149 | 301 | 586 | 1162 | 2325 | 4728 | 9284 | |
[1024] 1024 × 768 |
![]() ![]() ![]() |
43 | 121 | 244 | 476 | 944 | 1889 | 3842 | 7543 |
![]() ![]() |
73 | 203 | 412 | 802 | 1590 | 3182 | 6147 | 12070 | |
![]() |
93 | 258 | 522 | 1016 | 2014 | 4030 | 7684 | 15087 | |
[640] 640 × 480 |
![]() ![]() ![]() |
87 | 242 | 489 | 953 | 1888 | 3778 | 7684 | 15087 |
![]() ![]() |
127 | 352 | 712 | 1386 | 2747 | 5496 | 10245 | 20116 | |
![]() |
175 | 484 | 979 | 1906 | 3777 | 7557 | 15368 | 30175 |
Built-in memory |
64MB | 128MB | 256MB | 512MB | 1GB | 2GB | 4GB | ||
---|---|---|---|---|---|---|---|---|---|
17m23s | 47m58s | 1h36m58s | 3h8m53s | 6h14m15s | 12h28m41s | 25h22m33s | 49h49m27s |
Recorded Pixels | Quality Levels | Built-in memory |
64MB | 128MB | 256MB | 512MB | 1GB | 2GB | 4GB |
---|---|---|---|---|---|---|---|---|---|
640 × 480 |
30fps![]() ![]() ![]() |
20s | 57s | 1m56s | 3m47s | 7m31s | 15m2s | 30m8s | 59m10s |
30fps![]() ![]() |
28s | 1m17s | 2m36s | 5m5s | 10m4s | 20m9s | 40m58s | 1h20m28s | |
30fps![]() |
42s | 1m57s | 3m57s | 7m42s | 15m15s | 30m32s | 1h16s | 1h58m20s | |
15fps![]() ![]() ![]() |
41s | 1m53s | 3m50s | 7m28s | 14m48s | 29m38s | 1h16s | 1h58m20s | |
15fps![]() ![]() |
56s | 2m34s | 5m13s | 10m10s | 20m8s | 40m18s | 1h18m48s | 2h34m44s | |
15fps![]() |
1m22s | 3m47s | 7m40s | 14m57s | 29m37s | 59m16s | 1h53m50s | 3h43m31s | |
320 × 240 |
30fps![]() ![]() ![]() |
33s | 1m32s | 3m6s | 6m3s | 11m59s | 23m59s | 48m47s | 1h35m47s |
30fps![]() ![]() |
45s | 2m4s | 4m12s | 8m12s | 16m14s | 32m30s | 1h4m2s | 2h5m43s | |
30fps![]() |
1m3s | 2m56s | 5m55s | 11m33s | 22m53s | 45m48s | 1h33m8s | 3h2m52s | |
15fps![]() ![]() ![]() |
1m3s | 2m56s | 5m55s | 11m33s | 22m53s | 45m48s | 1h33m8s | 3h2m52s | |
15fps![]() ![]() |
1m27s | 4m2s | 8m9s | 15m53s | 31m28s | 1h2m58s | 2h8m4s | 4h11m27s | |
15fps![]() |
2m7s | 5m52s | 11m51s | 23m6s | 45m47s | 1h31m36s | 2h50m45s | 5h35m16s |
* The maximum length for one file is 24 hours for voice recording.
* The maximum size for one file is 2GB for moive.
