Digital SLR Cameras: K20D

K20D Main Specifications
Effective Pixels | approx.14.6 megapixels |
---|---|
Image Sensor | Total pixels: approx.15.07 megapixels Type: CMOS with a primary color filter Size: 23.4mm x 15.6mm |
Color Depth | 8 bit (JPEG) or 12 bit (RAW) |
Recorded Pixels | JPEG: [14.6M] 4672 x3104 pixels, [10M] 3872 x 2592 pixels, [2M] 1824 x 1216
pixels RAW: [14.6M] 4672 x 3104 pixels |
Sensitivity (Standard output sensitivity) |
Auto, Manual : ISO100 - 3200(1EV steps or 1/2EV steps) can be expand to ISO6400,Bulb mode:up to ISO1600 |
Recording Formats | RAW(Original), JPEG (Conforms to Exif 2.21), Conforms to DCF (Design rule of Camera File system)2.0 |
Image Formats | Compressed: JPEG - Baseline (![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() ![]() Compressed: RAW (PEF) Non-compressed: RAW (DNG) |
Storage Media | SD , SDHC memory card |
White Balance | Auto, Daylight, Shade, Cloudy,Tungsten Light, Fluorescent Light (W, D, N), Flash, Manual setting, with WB fine adjustment |
Viewfinder | Type: Pentaprism type Focusing screen: Natural-Bright-Matte II focusing screen Field of view: approx.95% Magnification: approx.0.95X (with 50mm F1.4 lens, infinity, -1m-1) Diopter adjustment: approx.-2.5 - +1.5m-1 |
LCD Monitor | Type: TFT color LCD monitor, brightness adjustable, Color adjustable, Wide
angle view Size: 2.7 inch Dots: approx. 230,000 dots |
Live View | TTL by Image sensor Field of view: approx. 100% Display: Enlargement (4X, 8x) , Grid pattern |
Preview Method | Live View, Digital preview , Optical preview |
Playback | One Image, Two Images, Index (4 or 9 or 16 thumb nails), Enlargement (up
to 32X, scroll available), Image Rotation, Folder view, Slideshow, Histogram,
Bright/Dark area Digital Filter: B&W(4 type), Sepia(3 type), Color (18 type), Color extract (6 type), Soft (three-level amount adjustable), Illustration, HDR (3 type), Slim (+/- 8 level amount adjustable), Brightness (+/- 8 level amount adjustable) |
Focusing System | Type: TTL Phase-matching 11-point wide autofocus system (SAFOX VIII) Focus Mode: AF-single (with focus lock); AF-continuous available Manual focus Focus Point: Auto, Select, Center AF assist lamp: avaiable (by Built-in Flash) |
Image Stabilizer | Type: Image sensor shift mechanism , Max 4 stops |
Dust Removal | Type: Image sensor moving mechanism and SP coating with Dust Alert |
Exposure Control | Metering System: TTL open-aperture 16-segment metering (coupled with lens
and AF information) Metering Mode: (1) Multi-segment metering (2) Center-weighted metering (3) Spot metering Exposure Range: EV 0 - 21 (at Standard Output Sensitivity 100 with 50mm F1.4 lens) Modes: (1) Green, (2) Program AE, (3) Sensitivity-Priority AE, (4) Shutter-Priority AE, (5) Aperture-Priority AE, (6) Shutter and Aperture Priority AE, (7) Metered Manual, (8) X speed, (9) Bulb Exposure Compensation: ±3 EV (0.5EV steps) , ±2 EV (0.3EV steps) Auto-bracketing: 3 or 5 frames within range of ±0.5EV, ±1.0EV, ±1.5EV, ±2.0EV (0.5EV steps) or ±0.3EV, ±0.7EV, ±1.0EV, ±1.3EV, ±1.7EV, ±2.0EV (0.3EV steps) AE Lock: availiable |
Shutter | Shutter Type: Electronically controlled vertical-run focal plane shutter Shutter Speed: 1/4000 - 30 sec. and bulb |
Drive Modes | Single-frame , Continuous (Hi, Lo), Burst, Self-timer (12s, 2s), Remote control
(0s, 3s), Remote control continuous, auto bracket, extended bracket and Multi-exposure Continuous shooting: approx. 3fps , sequence : until 38 frames (JPEG and continuous (Hi)) , 14 frames (RAW(PEF)) , 16 frames (RAW(DNG)) approx. 2.3fps , sequence : until the memory card becomes full (JPEG and continuous (Lo)) , 14 frames (RAW(PEF)) , 16 frames (RAW(DNG)) Burst mode: approx. 21fps , sequence : 115 frames (1.6M ![]() ![]() ![]() |
Built-in Flash | Type: Built-in retractable P-TTL pop-up flash Guide number: approx. 13 (Standard Output Sensitivity 100/m) Angle of view coverage: 28mm wide-angle (equivalent to 35mm) |
Flash Synchronization | Hot shoe, X-sync socket, sync-speed: 1/180 sec., P-TTL, high-speed-sync, wireless-sync with PENTAX dedicated flash |
Data Folder | Folder Name: Date (100_MMDD•••) / PENTX (100PENTX, 101PENTX•••) , File Name: Standard / User customize |
Power Sources | Rechargeable D-LI50 lithium-ion battery Optional AC adapter also available. |
Battery Life | Number of recordable images: approx. 530*1 (50% use Flash) , approx. 740*2 (Normal Recording) Playback time: approx. 330 minutes*2 |
Interfaces | USB2.0 (HI-SPEED)/Video , DC input , Cable switch, X-sync socket |
Lens Mount | PENTAX KAF2 bayonet mount Usable Lens: PENTAX KAF2-, KAF-, and KA-mount lenses. * Power zoom function available. K-mount lenses usable with restrictions. S-mount lenses, 67/645 lenses usable with adapter and with restrictions. |
Dimensions | approx. 141.5(W) x 101(H) x 70(D)mm (5.6 x 4.0 x 2.76 inches) |
Weight | approx. 715g (25.2 oz.) without battery and SD memory card. approx. 800g (28.2 oz.) loaded and ready with battery and SD memory card |
*1 Recording capacity shows approximate number of shots recorded
during CIPA-compliant testing. Actual performance may vary depending on operating
conditions.
*2 According to the result of PENTAX in-house testing.
K20D Storage capacity
RAW | RAW | JPEG | ||||||||
---|---|---|---|---|---|---|---|---|---|---|
Recorded Pixels | 4672 × 3104 |
4672 × 3104 |
4672 × 3104 |
3872 × 2592 |
||||||
Quality Level | PEF | DNG | ![]() ![]() ![]() ![]() |
![]() ![]() ![]() |
![]() ![]() |
![]() |
![]() ![]() ![]() ![]() |
![]() ![]() ![]() |
![]() ![]() |
![]() |
512MB | 20 | 20 | 34 | 58 | 105 | 205 | 50 | 84 | 148 | 308 |
1GB | 40 | 40 | 68 | 117 | 212 | 411 | 101 | 168 | 296 | 616 |
2GB | 82 | 82 | 138 | 239 | 429 | 830 | 206 | 343 | 602 | 1254 |
4GB | 161 | 161 | 272 | 469 | 843 | 1630 | 404 | 674 | 1183 | 2463 |
8GB | 329 | 329 | 554 | 955 | 1717 | 3319 | 824 | 1372 | 2408 | 5012 |
JPEG | ||||||||
---|---|---|---|---|---|---|---|---|
Recorded Pixels | 3008 × 2000 |
1824 × 1216 |
||||||
Quality Level | ![]() ![]() ![]() ![]() |
![]() ![]() ![]() |
![]() ![]() |
![]() |
![]() ![]() ![]() ![]() |
![]() ![]() ![]() |
![]() ![]() |
![]() |
512MB | 88 | 142 | 245 | 457 | 230 | 368 | 616 | 1118 |
1GB | 176 | 285 | 491 | 915 | 461 | 737 | 1233 | 2238 |
2GB | 359 | 579 | 991 | 1862 | 931 | 1499 | 2458 | 4390 |
4GB | 705 | 1138 | 1946 | 3657 | 1828 | 2943 | 4827 | 8620 |
8GB | 1436 | 2317 | 3961 | 7442 | 3721 | 5990 | 9824 | 17544 |
