RDC-2E
RDC-2e
ITEM | DESCRIPTIONS |
CCD | 410,000pixel CCD with complementaly color checkers, Progressive |
---|---|
CCD size | 1/4" |
LCD monitor | 1.8" TFT LCD (Detachable) |
Finder | Optical/LCD |
Recording media | Internal 2MB PCMCIA card |
Resolution | 768 x 576 |
Image quality mode | F/N/E |
Recording capacity (Image recording mode) | Internal: F 10/N 20/E 41 5MB ATA: F 25/N 51/E 103 |
File size | F: 192KB N: 96kB E: 48KB |
File format | DSC(J6I) |
Recording Mode | Still Image/Document/Continuous |
Remote Control Unit | |
Shooting range | 1cm - |
Macro mode | 1cm - |
Macro mode | |
Lens | f3.7mm(35mm on 35mm format) |
Shutter | Mechanical,1/8-1/1000 sec. |
Focus | Auto(TTL CCD AF) |
ISO sensibility | Approx.100 |
Exposure | AE Centerweighted |
Exposure | ±2.0EV (0.5 EV steps) |
Exposure Mode | Programmed AE, TTL CCD Method |
White balance | Auto |
Continuous shooting | |
Interfaces PCI/F | PC card, serial cables(RS232C) |
Transmission time | Max. 115.2Kbps |
Interfaces Audio/Video | Video (NTSC/PAL) |
Video output | |
Video signal | NTSC or PAL |
Date&time setting | |
Auto playback | (with DR-2) |
Auto Power Off | Activates when camera is not used for approx. 5min. |
Lens barrier | |
Tripod screw hole | 1/4-20 UNC 5.7mm max. bolt length |
Tripod screw hole | |
Battery | 4 x AA alkaline (NiCd/NiMH) |
Power requirement | BATT 6V, DC 5V |
Dimension(WxHxD) | 143 x 27 x 76mm/5.6 x 1.1 x 3.0in. |
Weight | 270g (9.6oz) |
Operational temperature | 0-40° |
