Q-mount Lenses

High-Performance Lenses

06 TELEPHOTO ZOOM

  • Zoom
  • High-Performance

This telephoto zoom lens is suitable when a distance separates the lens and the subject, such as for sports or landscapes.

This is a compact, lightweight telephoto zoom lens that enables a bright open F value of F2.8 over the entire zoom range. This lens enables expression of out-of-focus (bokeh) effect and provides impressive delineation performance by effectively correcting chromatic aberration, which is only possible with large-aperture lenses. This also enables use of a high-speed shutter in dim locations and is effective at reducing blurring due to hand shaking. This lens supports the medium telephoto to full telephoto shooting range equivalent to 69mm to 207mm in the 35mm film format when the Q7 is attached, and it can be used for a wide range of photography, including portraits, sports, and landscapes.

15mm to 45mm (equivalent to 69.0 to 207.0 mm in 35mm film format) F2.8

Built-in lens shutter Built-in ND filter SP Coating Auto-aperture Metal-mount

About lens technology

Lens Front-cap / Q Lens Mount-cover Included, Hood : PH-RBA40.5 Optional
JAN-Code / 4549212 217548

Discontinued

Sample Images

  • Aperture F2.8, Shutter speed 1/125sec, Focal length 44.5mm

  • Aperture F2.8, Shutter speed 1/1600sec, Focal length 44.1mm

  • Aperture F2.8, Shutter speed 1/500sec, Focal length 20.5mm

  • Aperture F2.8, Shutter speed 1/50sec, Focal length 42.8mm

  • Aperture F4.0, Shutter speed 1/125sec, Focal length 44.7mm

  • Aperture F4.5, Shutter speed 1/50sec, Focal length 45.0mm

Features / Specifications

1. Telephoto zoom lens featuring F2.8 over the entire range
This lens provides a bright, open F-value of F2.8 over the entire zoom range. This allows rendering of out-of-focus (bokeh) effects with an outstanding level of quality that is possible only with large-aperture lenses and enables shooting at high shutter speeds even in dim locations for reducing the adverse effects of hand shaking. When attached to a PENTAX Q mount digital SLR camera, this lens supports the medium telephoto to full telephoto shooting range equivalent to 83mm to 249mm in the 35mm film format (69mm to 207 mm in the 35mm film format, when attached to a PENTAX Q7 mount digital SLR camera), and it can be used for a wide range of photography, including portraits, sports, and landscapes.
2. High delineation performance
The optical system uses two ED (extra-low dispersion) glass lenses and one extraordinary low-dispersion glass lens for enabling superior delineation performance with corrected chromatic aberration over the entire zoom range.
3. Compact, lightweight design
Featuring a compact, lightweight design with length of 56mm, diameter of 50mm, and weight of only 90g for enabling an enjoyable and carefree shooting experience and easy portability. A click device is provided between the focal length of 15mm and the retracted state, and a collapsible mechanism is used to enable storing of the lens in a compact size.
4. Other features
[1] "Quick-Shift Focus System" for enabling manual focus operation after focusing by AF without any switching operation
[2] SP (Super Protect) coating for protecting the lens surface from water and dirt
Type Telephoto Zoom
Focal length (Equivalent to 35mm format) 15-45mm(69-207mm) ※Q7 Length
Maximum aperture F2.8
Angle of View 35°-12° ※Q7 Angle
Lens construction 14 elements / 10 groups
No. of diaphragm blades 5
Closest focusing distance 1.0m
Maximum reproduction ratio Approx. 0.05x
Filter size 40.5mm
Diameter x length 50 x 56 mm
Weight Approx. 90g
