Digital SLR Camera: *istDL
*ist DL
Features Specification Design Accessories Sample Images FAQ
Extra-Large, High-Resolution LCD Monitor to Facilitate Camera Operation and On-the-Spot Image Preview
The *istDL features an extra-large 2.5-inch LCD monitor to make image viewing extra easy during shooting and playback. In addition, all control buttons and switches, including the multi-function four-way controller, are ideally positioned for speedy, effortless camera operation.
On-Screen Operation/Function Guidance
Visual guidance for Auto Picture Program modeIn addition to the menu screen, the LCD monitor provides visual guidance to describe exposure modes and operational procedures.
Large Letters/Icons for At-a-Glance Confirmation
The LCD monitor displays menus and settings with large, easy-to-read letters and icons for easy, quick confirmation.
Main menu screenFunction (Fn) screen in shooting modeWhite balance set-up screen
210,000 Pixels for High-Quality Monitor Images
The extra-large LCD monitor makes the following features even more functional and enjoyable:
  • Slide show: Automatically plays back recorded images in succession.
  • Histogram: Offers a graphic display of exposure levels, along with an overexposure warning.
  • Brightness control: Lets the user adjust the LCD monitor’s brightness.
  • Nine-image display: Displays thumbnails of nine different images at once.
  • 12X zoom display: Magnifies the image for pinpoint confirmation of the focusing status and the subject’s expression.
???j?^?[ñaeeoe
12h{?gea‹œ\?|
Large LCD Panel for Easy Data Reading
Large LCD Panel for Easy Data ReadingThe large LCD data panel on the camera’s top panel lets you easily confirm the camera’s operational status, including exposure settings, battery level and exposure frame number.
Ideally Sized and Designed for SLR Beginners
Super-Compact, Ultra-Lightweight Body with User-Friendly Design
Despite its sophisticated appearance and advanced features, the *istDL weighs just 470 grams (camera body only) and is designed to be extremely maneuverable, making digital SLR photography easier and friendlier for photographers of all levels.
The combination of a non-slip rubber grip and a finger hook assures a firm, comfortable hold of the camera. The versatile SD memory card is used as the storage media. The multi-source power system accepts world-standard AA-sized batteries. The built-in flash automatically pops up in the dark or against backlight.
The combination of a non-slip rubber grip and a finger hook assures a firm, comfortable hold of the camera. The versatile SD memory card is used as the storage media. The multi-source power system accepts world-standard AA-sized batteries. The built-in flash automatically pops up in the dark or against backlight.
Optimum Creativity Assured by Large-Format CCD and 6.1 Effective Megapixels
Optimum Creativity Assured by Large-Format CCD and 6.1 Effective MegapixelsThe *istDL boasts a large CCD image sensor, which receives a vast amount of data with unfailing precision for the reproduction of true-to-life images.
New Imaging Engine for Sharp, High-Precision Image Reproduction
• Reduced noise for sharp, crisp images
• Faithful color reproduction for true-to-life images
• Rich gradation for beautiful details
Three Different Ways to Capture an Image, Depending on the User’s Preference and Skills
Picture Mode to Create a Specific Visual Effect
Just select one of seven Picture modes — Standard, Portrait, Landscape, Macro, Action, Night scene portrait and Standard flash-off — and you’re assured of beautiful images, all automatically, with the desired visual effect.
Standard mode Portrait mode Landscape mode Macro mode
Standard mode Portrait mode Landscape mode Macro mode
Handles all types of subjects and occasions, including casual snapshots. Produces beautiful portraits with natural skin tones. Captures spectacular scenery with clear blue skies and lively greens. Takes dramatic close-ups of insects and flowers by adjusting saturation and contrast.

Action mode Night scene portrait mode Standard flash-off mode
Action mode Night scene portrait mode Standard flash-off mode
Captures an active subject in focus with a high shutter speed. Beautifully illustrates both the subject in foreground with a flash and the nighttime illumination in background with a large aperture. Prevents a flash discharge and creates the distinctive atmosphere using ambient light only.
Auto Picture Program for Point-and-Shoot SLR Photography
Auto Picture Program for Point-and-Shoot SLR PhotographyWhen the mode dial is set to “AUTO PICT,” the *istDL automatically and instantly selects one of five distinctive Picture modes — Standard, Portrait, Landscape, Macro and Action — as soon as the camera is pointed at the subject and the shutter release button is half depressed. This assures SLR-quality images, frame after frame and on every occasion, with minimal effort.
Multi-Mode Exposure System for Greater Visual Control
Multi-Mode Exposure System for Greater Visual ControlProgrammed AE mode
The optimal combination of aperture and shutter speed is automatically selected by the camera.

Aperture-Priority AE mode
The user sets the desired aperture to reduce or expand the depth of field; the camera automatically selects the corresponding shutter speed.

Shutter-Priority AE mode
The user sets the desired shutter speed to freeze or stretch the subject’s movement; the camera automatically selects the corresponding aperture.

Metered Manual mode
Commonly employed by advanced photographers, this mode allows the user to manually set both aperture and shutter speed to create artistic and extraordinary visual effects.

Bulb mode
Often used in specialized applications, this mode lets the user expose the image for any duration, as long as the shutter release button is depressed.

Optimum Control of Light and Color Assured to Preserve Once-in-a-Lifetime Moments

Optimum Control of Light and Color Assured to Preserve Once-in-a-Lifetime MomentsTop Shutter Speed of 1/4000 Second
With a maximum shutter speed of 1/4000 second, you can not only freeze the action of a fast-moving subject, but also use larger apertures to reduce the depth of field for more dramatic images.

Responsive Shutter to Capture the Decisive Moment
Assisted by the high-speed AF system, the responsive shutter unit minimizes shutter-release time lag to help you preserve once-in-a-lifetime shutter opportunities.

Consecutive Shooting at 2.8 Frames per Second
In addition to single-frame advance, the *istDL offers consecutive advance of up to five frames at a speed of approximately 2.8 frames per second. This allows you to capture a series of an active subject’s images and select the best one afterwards.
Consecutive Shooting at 2.8 Frames per Second
Choice of Finishing Touch
Bright Natural
Bright Natural
Emphasizes vivid colors, such as blue skies and lively greens. Creates a natural atmosphere with subdued colors and subtle shades.
Multi-Application Flash System

Multi-Application Flash SystemBuilt-in P-TTL Auto Flash
Built into the pentaprism housing, this flash offers such useful functions as automatic discharge level adjustment and red-eye reduction.

Dedicated Accessory Flash
The optional AF360FGZ dedicated flash unit offers a wide range of advanced flash applications.

Choice of White Balance Control
In addition to auto white balance control, the *istDL lets you preset the white balance level for eight different light sources. Manual control is also available for more minute adjustment.
White balance: Auto White balance: Preset for incandescent lamp
White balance: Auto White balance:
Preset for incandescent lamp
Auto Bracketing for Three Distinct Images of the Same Subject
This function allows you to take the image at three different exposure levels and select the best one afterwards, saving you the time and trouble required for mid-shooting exposure adjustment.
-1/2EV ?}0EV +1/2EV
-1/2EV ±0EV +1/2EV
Reliable 16-Segment Multi-Pattern Metering
This sophisticated metering system exposes the subject beautifully, even when the overall image contains an intricate combination of highlight and shadow areas.
  • Center-weighted metering: A user option to put emphasis on the central area, with consideration to peripheral areas.
  • Spot metering: A user option to measure the small central area only.

High-Speed, High-Precision Autofocus
The *istDL incorporates a three-point autofocusing system that offers a wide coverage area formed by one central sensor and two side sensors.
  • Manual focus: A user option to enable manual focus operation.
Note: All DA- and D FA-series lenses feature the PENTAX-original Quick Shift focusing system, in which the focus mode is automatically switched to manual simply by turning the focus ring after the subject is captured in focus.

Five-Level Control over Saturation, Contrast and Sharpness
  • Saturation: A factor that determines the vividness of a color.
  • Contrast: A factor that determines the difference in color or brightness.
  • Sharpness: A factor that determines the clarity of lines and edges.

Choice of Standard Output Sensitivity
In the auto mode, the sensitivity is automatically shifted to an adjacent setting when the camera detects the lighting level beyond the initial setting. The manual mode is also available in five steps between ISO 200 and ISO 3200.
Reliable 16-Segment Multi-Pattern Metering
Electronic Preview for Quick Depth-of-Field Confirmation
Electronic Preview for Quick Depth-of-Field ConfirmationWith a single lever action, you can confirm the in-focus area quickly and effortlessly in the viewfinder.
Easy-to-Use Exposure Compensation
The desired exposure compensation value can be set with a simple operation of the Av button and the select dial.

AE Lock to Memorize Exposure Settings
The *istDL memorizes the current exposure settings instantly when you point the camera at the subject and press the AE-L/key button, allowing you to capture the image at the same exposure level even after you change the image composition. This function gives you greater exposure accuracy when used in combination with spot metering.
AE Lock to Memorize Exposure Settings
Giving New Life to Recorded Images through Processing, Browsing, Printing and Filing
Built-In Digital Filters for Computer-Free Image Editing
Unedited image
Unedited image Soft filter Soft filter Soft filter
Soft filter
The subject is enveloped in soft light, while retaining its profile.
The degree of the soft-focus effect can be shifted in three levels.


Black-and-white filter Sepia filter
Black-and-white filter Sepia filter
Full-color images can be converted to monochrome images for more artistic expressions. Sepia tone is added to the image to create a nostalgic atmosphere.


Unedited image
Unedited image Slim filter Slim filter
Slim filter
The subject can be made fatter or slimmer to create an eye-catching image.
Viewing Images on TV
Viewing Images on TVSimply connect the *istDL to a TV monitor using the included AV cable, and you will enjoy recorded images on a larger screen.
Printing Images
The *istDL’s PictBridge compatibility lets you easily print recorded images without the need for a computer, when it is connected to a printer using the included USB cable.

PictBridge
Printing Images
Browsing Images on Computer

USB2.0 HIGH SPEEDUSB2.0 HIGH SPEED
The *istDL is compatible with USB2.0 HIGH SPEED, which assures swift, effortless transfer of a large-volume image data to a computer.

Choice of Color SpaceChoice of Color Space
The *istDL offers two different color spaces (the international-standard sRGB and the industry-standard AdobeRGB) to meet the required data output specifications.

Browsing Images on Computer
Standard Image Browser and Processing Software Included
Image Browser Software with Functions to Edit Existing Images

PENTAX PHOTO Browser 2.1
This software facilitates various post-shooting operations, including the transfer of recorded images to a computer, and the filing, browsing, editing, simple revisions, and printing of transferred images on a computer.

  • Reinforced browser functions
  • Flexible layout of a pane
  • Two new printing functions: (1) Index printing; (2) Photo printing
  • Addition of a slide show function (compatible with dual-screen applications)
  • Addition of simple image correction and image rotation functions
  • Addition of a check box (or docketing) function
  • Addition of a sorting function
PENTAX PHOTO Browser 2.1
RAW Data and Image Processing Software

PENTAX PHOTO Laboratory 2.1
This software not only processes and files images recorded as RAW data, but also offers user-friendly operations with reinforced preview functions, including preview screen zooming.

  • High-speed processing of RAW data
  • Flexible layout of control panels
  • Reinforced preview functions: (1) Choice of four image sizes (S, M, L, and full size); (2) Addition of a partial magnification window (at 25%, 50%, 100%, 200% and 400% magnifications); (3) Restoration of details in overexposed and underexposed areas
  • Reinforced color temperature set-up function
  • Choice of five compression rates for JPEG files
PENTAX PHOTO Laboratory 2.1
SD Memory Card as Storage Media
SD Memory Card as Storage MediaThe *istDL uses the compact, reliable SD memory card as its storage media. It even accepts large-capacity SD memory cards with storage capacities over 1GB.
